GYKZ-01 induction slag resistance experimental furnace

The equipment is used to measure the slag corrosion resistance of refractory products. The equipment uses medium frequency in

The equipment is used to measure the slag corrosion resistance of refractory products. The equipment uses medium frequency induction heating steel block, after the steel block is melted, the slag is put into the furnace. It can measure the temperature of molten steel accurately and continuously. The crucible method (making the whole crucible of refractory materials or building the crucible with multiple samples) and immersion test can be carried out, and the crucible method and immersion test can also be carried out at the same time. The test tube with multiple samples (four 40 × 40 × 230 samples suspended in the slag liquid for planetary motion) can be carried out at the same time. It has water cut-off protection function.

GYKZ-01型感应抗渣实验炉(图1)

 正常使用温度 Working temperature(℃)
1650
 额定容量 Rated capacity(kg)
steel钢25 slag渣1~3
 融化时间 Melting time(h)
1
 额定频率 Rated frequency(Hz)
1000
 冷却水压力 Pressure of cooling water(MPa)
0.2~0.3
 试样尺寸 Size of sample(mm)
坩埚crucibleφ150×450(1个)或试样samples40×40×230(4个)
 控制柜尺寸 Size of control cabinet(mm)
1400×800×1920
 电源 Power supply
380V 50Hz 50kkW
 输出电压 Output voltage(v)
750
 重量 Weight(kg)
1200
