CSL series reburning experimental furnace

The equipment is widely used as heating furnace in metallurgy, building materials, machinery, chemical industry and other ind

The equipment is widely used as heating furnace in metallurgy, building materials, machinery, chemical industry and other industries. It is especially suitable for testing and sintering of refractories in various atmospheres. The equipment is manufactured in accordance with the requirements of GB / T 5988 "dense shaped refractory products test method for linear change of reheating".

CSL系列重烧实验炉(图1)


 型号/参数 Model/Specification使用温度 Working temperature(℃)炉膛尺寸 Hearth Size(mm)功率 Power(kW)
 CSL13-41-28-38-2-31350530×310×25028
 CSL13-41-28-38-3-31350530×310×25028
 CSL16-24-25-38-2-31650530×240×19025
 CSL16-24-25-38-3-31650530×240×19025
 CSL16-37-36-38-3-31650620×240×25036
 CSL16-56K-50D-38-3-31650720×310×25050

Model Description: meaning of csl16-37-36-38-3-3y: reheating furnace (CSL), operating temperature of 1650 ℃ (16), effective volume of 37l (37), power of 36kw (36), power supply of 380V (38), three loops (3), three-point temperature control (3), instrument control (y).
