QGJ-01 cutting machine

Qgj-01 cutting machine is a kind of special equipment for cutting various refractory samples. The equipment is equipped with

Qgj-01 cutting machine is a kind of special equipment for cutting various refractory samples. The equipment is equipped with diamond saw blade for manual sample preparation.

主轴转速 Rotated speed of principal axis(r/min)1440
 工作台面 Worktable(mm)500×500
 锯片直径 Diameter of saw piece(mm)φ450
 轨道长度 Orbit length(mm)1300
 最大切削尺寸 Max.cutting size(mm)500×480×145
 冷却水接口直径 Diameter of cooling-water interface(mm)φ20
 冷却水压 Cooling-water pressure(MPa)>0.2
 主机尺寸 Size of mainframe(mm)1300×520×1500
 电源 Power supply380V 50Hz 4kW
 净重 Weight(kg)560
