GWND-02p high temperature viscometer
The equipment is used to measure the liquid viscosity of mold powder, glass and glaze. The equipment is manufactured accordin
The equipment is used to measure the liquid viscosity of mold powder, glass and glaze. The equipment is manufactured accordin
The equipment is used to measure the liquid viscosity of mold powder, glass and glaze. The equipment is manufactured according to the national standard Yb / T 185 test method for viscosity of mold fluxes for continuous casting. IPC industrial computer is used for automatic control, friendly interface, high temperature control precision, dynamic real-time display curve, original data can be converted into excel storage format, and test report can be read and printed at any time.
使用温度 Working temperature(℃) | 1400 |
粘度测量范围 Viscosity range(Pa.s) | ≥0.1 |
炉膛尺寸 Hearth size(mm) | φ180×190 |
升温速率 Heating-up Rate(℃/min) | 0~30 |
保温温度精度 Temperature accuracy in soaking(℃) | ±2 |
主机尺寸 Size of mainframe(mm) | 830×650×1730 |
电源 Power supply | 380V 50Hz 12kW |
重量 Weight(kg) | 650 |
