BLSC-01 glass phase exudation temperature measuring instrument
The equipment is used to measure the exudation temperature of glass phase in casting refractories. The equipment is manufactu
The equipment is used to measure the exudation temperature of glass phase in casting refractories. The equipment is manufactu
The equipment is used to measure the exudation temperature of glass phase in casting refractories. The equipment is manufactured in accordance with the requirements of national standard JC / T 805 test method for glass phase exudation temperature in refractories for glass furnace. IPC industrial computer is used for automatic control, with high temperature control precision (expert fuzzy control algorithm is applied), and test results are recorded automatically. The temperature time curve can be drawn to show the sample image and the exudation temperature of the glass phase in the sample.
使用温度 Working temperature(℃) | 1650 |
升温速率 Heating-up Rate(℃/min) | 5~20 |
放大倍数 Magnification times | 20 |
测量精度 Measuring accuracy(℃) | ±2 |
试样尺寸 Size of sample(mm) | 4×4×4 |
图像分辨率 Image resolution | 768×576 |
电源 Power supply | 380V 50Hz 3kW |
