HRY series high temperature soft creep testing machine
The equipment is used to measure the load softening temperature or creep rate of refractories. The equipment is manufactured
The equipment is used to measure the load softening temperature or creep rate of refractories. The equipment is manufactured
The equipment is used to measure the load softening temperature or creep rate of refractories. The equipment is manufactured in accordance with the requirements of Yb / T 370 test method for load softening temperature of refractories (non differential heating method), GB / T 5989 test method for load softening temperature of refractories (differential heating method) and iso3187 determination of creep under pressure of refractories. The box type furnace body is adopted in the new high temperature soft creep testing machine. It is very convenient to load samples and replace upper and lower pressure bars. The non friction loading system makes the loading accuracy higher, and the deformation is measured by differential method. It can test multiple samples at the same time with high efficiency and good energy saving.
型号/参数 Parameter/Specification | HRY-01 | HRY-02/1 | HRY-02/2 | HRY-03 | HRY-04 | HRY-04/2 | HRY-04/3 | HRY-04/5 |
正常使用温度 Working temperature(℃) | 荷软Under load:1700℃ 蠕变Creep:1550℃ | |||||||
升温速率 Heating-up rate(℃/min) | 0~10 | |||||||
控温精度 Temperature accuracy in soaking(℃) | ±2 | |||||||
变形测量范围 Deformation range(mm) | 0~10 | |||||||
变形测量精度 Deformatiion accuracy(%) | 0.1 | |||||||
加荷范围 Loading range(N) | 50~500 | |||||||
执行标准 Execution standard | YB/T 370 | YB/T370 GB/T5989 GB/T5073 | ||||||
试样个数 Quantity of sample | 1 | 1 | 2 | 1 | 1 | 2 | 3 | 5 |
电源 Power supply | 380V 50Hz 220V 50Hz | |||||||
重量 Weight(kg) | 350 | 585 | 600 | 530 | 550 | 650 | 700 | 800 |
