ZYJ-01 drill prototype
Model zyj-01 drilling prototype is a special equipment for drilling soft, creep and expansion samples. The equipment is equip
Model zyj-01 drilling prototype is a special equipment for drilling soft, creep and expansion samples. The equipment is equipped with diamond bit, and samples are prepared manually.
| 最大钻孔直径 Max.drill diameter(mm) | φ50 |
| 最大加工深度 Max.machining depth(mm) | 125 |
| 主轴转速 Principal axis rotated speed(r/min) | 160 250 500 800 1050 |
| 主轴至底工作面距离 Distance of axes to workbench(mm) | 280～730 |
| 底座工作面尺寸 Dimension of workbench base(mm) | 400×380 |
| 主机尺寸 Size of mainframe(mm) | 954×440×1604 |
| 净重 Weight(kg) | 240 |
